ZTPS – 25089 - PNEUMATIC SEALER
A medium-duty pneumatic steel strap sealer designed for industrial and commercial applications, offering strong joint efficiency, low maintenance, and user-friendly operation.
The ZTPS-25089 Pneumatic Sealer is engineered for medium-duty steel strapping tasks in industrial and commercial environments. Built with precision, it supports strap thicknesses from 0.64 mm to 0.89 mm and widths up to 25.4 mm (1"). Its single-notch reverse type (up cut) sealing ensures secure fastening with joint efficiency between 75% and 80%. Operating at an air pressure of 5.5–6.0 kg/cm², the tool delivers consistent performance while remaining lightweight at just 3.2 kg (7.05 lb). Compact dimensions (259 × 111 × 253 mm) make it easy to handle, while its robust design minimizes maintenance needs. Ideal for regular duty or high tensile steel strapping, this sealer is a dependable solution for packaging operations requiring durability and efficiency.
SPECIFICATIONS
| Strap Thickness | Strap Width | Grade | Joint Efficiency | Operating Air Pressure | Weight | Dimension (L × W × H) |
|---|---|---|---|---|---|---|
| 0.64 – 0.89 mm 0.025” – 0.035” | 25.4 mm 1" | Regular Duty or High Tensile | 75% to 80% | 5.5 – 6.0 kg/cm² | 3.2 kg 7.05 lb | 259 × 111 × 253 mm 10.19” × 4.37” × 9.96” |
Features
- Medium-duty pneumatic steel strap sealer
- Single-notch reverse-type (up-cut) sealing system
- Smooth operation with minimal maintenance
- Reliable, strong joint formation
- Lightweight and ergonomic design for easy handling
Usage
Ideal for industrial and commercial packaging environments requiring dependable steel strapping—such as manufacturing units, warehouses, logistics hubs, and heavy-duty bundling operations.
Add your review
Your email address will not be published. Required fields are marked *
Please login to write review!
Looks like there are no reviews yet.
It is ideal for medium-duty industrial and commercial steel strapping operations such as packaging, bundling, and securing heavy materials.
It supports steel straps with a thickness of 0.64 – 0.89 mm and a width of 25.4 mm (1").
Yes, the tool is compatible with Regular Duty and High Tensile steel straps.
It provides a single-notch reverse type (up-cut) seal for strong and secure joint formation.
The machine operates optimally at 5.5 – 6.0 kg/cm².
It delivers 75% – 80% joint efficiency, ensuring secure strapping performance.
No. It is operation-friendly with low maintenance, designed for long-term durability.
It weighs 3.2 kg (7.05 lb), making it relatively lightweight and easy to handle.
Yes, its pneumatic mechanism supports consistent, repetitive sealing without operator fatigue.
It is widely used in manufacturing units, warehouses, logistics hubs, construction material yards, and heavy packaging lines.
